PRINTER VKP80III ETH USB SIDE CONNECTORS

Kiosk printer 80mm 200DPI ETH

Overview

• The Cut VKP80IIIETH (Custom VKP80III ETH) is a compact thermal kiosk printer designed for ticket and receipt printing in self-service machines.
• Features 200 DPI print quality and high speed (>250 mm/s) with present/eject/retract functions.
• Equipped with anti-jam system and automatic error recovery to reduce downtime.

Main specifications

• Paper width: 50–82.5 mm.
• Paper thickness: 60–110 g/m²; supports roll and fan-fold paper formats.
• Printing resolution: 200 DPI; max speed: >250 mm/s; presenter speed >1000 mm/s.
• Printhead lifespan: long-life head (typical ~200 km of printed paper).
• Form factor and mounting: compact body (~116×143×76 mm), multi-position roll holder (6 total positions), right or left paper feed.
• Interfaces: RS232, USB 2.0 Full Speed, Ethernet available on ETH model.
• Cutter: programmable cut modes (full cut, form feed + cut, etc.).

Applications

• Self-service machines: parking, ticketing, kiosks and POS where reliability and compact footprint are required.
• Kiosk terminals, ticket dispensers, access control and vending applications.
• Payment points and services requiring 1D/2D barcode and QRCODE printing.

Consumables & maintenance

• Easy paper replacement with multi-position roll holder; supports large diameter rolls (up to 250 mm) and fan-fold paper.
• Design: illuminated bezel, cleaning and self-check commands for the printhead.
• Maintenance: anti-jam and auto-eject/retry minimize on-site interventions.

Detailed description

• The Custom VKP80III ETH is built for environments that demand reliability, fast ticket issuance and minimal footprint. The 200 DPI ensures clear receipts and barcodes; >250 mm/s print speed supports quick customer flows. Networked ETH variant provides Ethernet connectivity for kiosk networks. The cutter can be configured for different modes, making the unit flexible across applications. Multi-position roll mounting and left/right feed options make integration into various cabinets straightforward. The anti-jam system with auto-retry and printhead self-diagnosis reduces operating costs and service visits. Robust mechanics and long-life printhead suit continuous operation in kiosks and outdoor vending with optional shutter accessories for harsher environments.

FAQ

• Q: What paper widths does the printer support?

  A: Supports 50–82.5 mm paper widths and various thicknesses (60–110 g/m²).
• Q: What interfaces are available on the ETH model?

  A: The ETH model includes Ethernet connectivity and also supports USB and RS232 depending on configuration.
• Q: What cut modes are available?

  A: Full cut and form feed + cut modes are programmable via command.
• Q: How robust is the paper jam handling?

  A: Anti-jam system with auto-eject/retry reduces downtime due to jams.
• Q: What is the printhead lifespan?

  A: Factory data indicates long-life printheads, typically designed for ~200 km of printed paper.
