| Product Features: |
• IC/RF read/write
• With cards pre-empty and empty detection
• Internal card receiving function with a card box or receiving channel
• Rs-232, support multi-unit communication
• Flexible adjustment of card thickness
• Support serial port and PC/SC in card reading &writing mode
• The most compact issuing machine with IC/RF card reading & wr |
General Specification
·PowerSupply:
DC 24V±5%
·CurrentComsumption:
StaticCurrent: 0.1A
Peak Current during Operation: 2.0A Normal Current Condition: 800mA
·CardFeeding-OutSpeed:
> 0.5 Cards/s (Transportation Speed)
·CommunicationInterface:
RS232C / USB (HID) (Ex-work setting: Default unit address is '0')
·CardDimensions:
Size:55×86mm
Thickness: 0.2mm~1.0mm(Ex-work standard: 0.8mm)
·Weight:
4.0 KgApprox.
·Dimensions:
Refer toStructure and Dimension Drawings
·CardStackingCapability:
120pcs in case of 0.76mm standard card (Available to set to 500pcs max.)
·CardPre-EmptyDetection:
7~50pcs±2pcs ( Default setting: 15pcs)
·EnviromentalCondition:
Operation: 0~50℃0~90% RH ( Without Condensing) Storage: -10~75℃ 0~90% RH ( Without Condensing)
·LifeTime:
1 million times
( In the condition: 20+/-5℃, 35~60%RH, Dispense cycle≤ 1pcs/min)
